SS3 Max white LED fog-light kit for compatible Sprinter vans.
Focused SAE J583 fog beam with SS3 TIR optics.
Foxbeam carbon-fiber-reinforced ASA brackets for a factory-style fit.
H11-to-DT adapters and Sprinter backlight harness included.
Installs without vehicle modification.
Engineered and assembled in the USA.
Overview
Replace the factory fog lights with two SS3 Standard LED pods. The included left and right Foxbeam brackets fit the factory fog openings. The adapters connect the pods to the factory fog-light wiring; the harness supports the amber backlight.
Fitment
Fits 2019–2026 Mercedes-Benz Sprinter vehicles with factory fog lights and the Exterior Lighting Package. Not for vehicles without that package.
What is included
Two SS3 Standard LED fog pods
Foxbeam left and right brackets
Two H11-to-DT 4-pin adapters
Sprinter backlight harness
Mounting hardware, six zip ties, and two T-taps
Warranty
Limited lifetime warranty on Diode Dynamics lighting; three-year warranty on Foxbeam brackets.
Specifications
Beam Angle: Fog, 80° x 8°
Bracket Color: Black
Color Temp: 6000
Compliance Rating: SAE J583 Foglamp Beam Pattern
DOT Approved: Yes
Grade Type: Performance
Housing Material: Aluminum
Intensity (lux): 18000
Intrusion Rating: IP69K Waterproof, High Pressure
Lens Material: Polycarbonate
Light Housing Color: Black
Measured Output (lumens): 3500
Mounting Hardware Included: Yes
Operating temperature: -40C to 85C (-40F to 185F)
Street Legal: Yes
Terminal Type: Pin
Voltage: 9-30
Wattage: 38.5
